Aluminium 2020/3030 Diagonal Support

€25,00 – €39,00 exkl. MwSt.

  • Dimensions: 195 x 30 x 19 mm
  • Material: EN AW 7075
  • Production: Precision CNC milling
  • Surface : (with minimal handling scratches)
    • Raw aluminium
    • Anodized black aluminium (batch 2)
  • Location: Made in Austria
  • Note:
    • Fits all 3030 aluminium extrusions
    • Fits all 2020 aluminium extrusions
    • M6x12 mm screws and nuts needed
    • No screws or nuts included
  • Shipping Batch 2: 14.04.2023 in Europe
  • Design: Credit goes to Simon Vez (VzBot)
Filter löschen

Links from external vendors

Item Description Thumbnail Link
Fabreeko Official Reseller in the USA. Fabreeko Online Shop
Raven 3D Tech Official Reseller in Australia. Raven 3D Tech Online Shop
Vector 3D Official Reseller in the United Kingdom. Vector 3D Online Shop
RatRig V-Core 3D Printers CoreXY printers in different sizes and configurations available. Based in Portugal. Ratrig V-Core RatRig V-Core
V-Core Printed Parts ASA/PA12CF15 3D printed parts out of ASA or PA12CF for a standard V-Core 3.1. Based in France. Ratrig V-Core BRS Engineering
Z-Upgrade (Vcore 3.x) 3D printed parts out of ASA or PA12CF for a V-Core 3.1 or 3.0 with optional SFU1204 ballscrew upgrade for high precision printing. Based in France. Ratrig V-Core BRS Engineering
Open Front idlers V1 3D printed parts out of ASA or PA12CF for an open front based V-Core printer with leadscrews or SFU1204 ballscrews. Based in France. BRS Open Front Idlers BRS Engineering
L3VER M2 Tensionner / Precision Motor Block 3D printed parts for decoupled motor mounts and belt tension system. Based in France. L3VER M2 BRS Engineering
BRS CF80 Filtration Filtration system with activated carbon + HEPA. Based in France. Filtration BRS Engineering

Zusätzliche Informationen

Surface

Silver Raw, Black Anodized

Ähnliche Produkte

  • X-Gantry-Alu-622mm v19 - SilverX-Gantry-Alu-622mm v19 - Black
    Ausführung wählen

    X-Gantry 622mm for RatRig V-Core 500

    €65,00 – €79,00 exkl. MwSt.
    • Dimension: 622 x 20 x 20 mm
    • Weight: 119 g (vs. 286 g of original 2020 extrusion)
    • System: Suitable for the RatRig V-Core 500
      • MGN12 linear rails
      • MGN9 linear rails
    • Material: EN AW 6060 T66
    • Production: Precision CNC milling
    • Surface : (with minimal handling scratches)
      • Raw aluminium
      • Anodized black aluminium (batch 2)
    • Note:
      • Mounting of the linear rail with M3x8mm screws (not included)
      • Prices excl. VAT
      • Made in Austria
    Ausführung wählen
  • X-Gantry-Alu-422mm v22 - SilverX-Gantry-Alu-422mm v22 - Black
    Ausführung wählen

    X-Gantry 422mm for RatRig V-Core 300

    €45,00 – €59,00 exkl. MwSt.
    • Dimensions: 422 x 20 x 20 mm
    • Weight: 86 g (vs. 194 g of original 2020 extrusion)
    • System: Suitable for the RatRig V-Core 300
    • Material: EN AW 6060 T66
    • Production: Precision CNC milling
    • Surface : (with minimal handling scratches)
      • Raw aluminium
      • Anodized black aluminium (batch 2)
    • Note:
      • Mounting of the linear rail with M3x8mm screws (not included)
      • Prices excl. VAT
      • Made in Austria
    • Shipping Batch 2: 14.04.2023 in Europe
    Ausführung wählen
  • X-Gantry-Alu-322mm v18 - SilverX-Gantry-Alu-322mm v18 - Black
    Ausführung wählen

    X-Gantry 322mm for RatRig V-Core 200

    €35,00 – €49,00 exkl. MwSt.
    • Dimensions: 322 x 20 x 20 mm
    • Accuracy :
      • Length: +- 0.01 mm
      • Thickness: +- 0.02 mm
      • Thread position: +- 0.01 mm
    • Weight: 68 g (vs. 148 g of original 2020 extrusion)
    • System: Suitable for the RatRig V-Core 200
    • Material: EN AW 6060 T66
    • Production: Precision CNC milling
    • Surface : (with minimal handling scratches)
      • Raw aluminium
      • Anodized black aluminium
    • Note:
      • Mounting of the linear rail with 6x M3x8mm screws (not included)
      • Prices excl. VAT
      • Made in Austria
    Ausführung wählen
  • Cast tooling plate - 529_529_10mmCast tooling plate - 529_529_10mmAusverkauft
    Ausführung wählen

    Bed Plate for RatRig V-Core 3 – 500

    €150,00 – €400,00 exkl. MwSt.
    • Dimension: 529 x 529 x 10 mm (original: 6 mm)
    • Material: EN AW-5083 cast tooling plate
    • Tolerance (of total length): +- 0.05 mm (22°C)
    • Options:
      • Without Magnets
      • With Magnets: 16 pieces with M3 screws (ISO 14581 M3)
    • QA Certificate: Created by a Mitutoyo CRYSTA-Apex V
    • Design: Credit goes to Wade Wendorf (Mandela Rose Works)
    Ausführung wählen
  • Griff-Ergo SilverGriff-Ergo Black
    Ausführung wählen

    Aluminium Handle Ergo

    €25,00 – €39,00 exkl. MwSt.
    • Dimensions: 192 x 50 x 18 mm
    • System: Suitable for 2020 and 3030 Extrusions
    • Material: EN AW 7075
    • Production: Precision CNC milling
    • Surface : (with minimal handling scratches)
      • Raw aluminium
      • Anodized black aluminium (batch 2)
    • Location: Made in Austria
    • Note:
      • 176 mm hole distance
      • M5 screw neeeded. No screws or nuts included
    • Design: Credit goes to Simon Vez (VzBot)
    • Shipping Batch 2: 14.04.2023 in Europe
    Ausführung wählen
  • Aluminium Joining Plate Bottom SilverAluminium Joining Plate Bottom BlackAusverkauft
    Ausführung wählen

    Aluminium 3030 Joining Plate Bottom

    €25,00 – €39,00 exkl. MwSt.
    • Dimensions: 118 x 118 x 19 mm
    • Material: EN AW 7075
    • Production: Precision CNC milling
    • Surface : (with minimal handling scratches)
      • Raw aluminium
      • Anodized black aluminium
    • Location: Made in Austria
    • System: Suitable for the RatRig V-Core
    • Note:
      • Fits all 3030 aluminium extrusions
      • Shall be used with rubber foot with metal insert 28*22*16.5mm
      • M6x16 mm screws and nuts needed
      • No screws or nuts included
    • Design: Credit goes to Dennis Jespersen (DJ_Designs) for an initial build
    • Shipping: 14.04.2023 in Europe
